EH-1400 Injection Slip Joint

Short Description:

Application:
Injection slip joint can absorb the expansion and compression caused by the temperature, and pipeline deformation caused by the building settlement. Used for firefighting pipeline, steam pipeline and hot water pipeline.


Product Detail

Product Tags

Specification:

Single Type

Nominal Bore

Movement/Total Length

100MM

200MM

300MM

20

600

800

1000

25

600

800

1000

32

600

800

1000

40

600

800

1000

50

600

800

1000

65

600

800

1000

80

700

900

1200

100

700

900

1200

125

700

900

1200

150

800

1000

1200

200

800

1000

1200

250

800

1000

1200

300

800

1000

1200

350

1000

1150

1300

400

1000

1150

1300

500

1000

1150

1300

600

1000

1150

1300

700

1200

1400

1500

Double Type

Nominal Bore

Movement/Total Length

200MM (100+100)

400MM(200+200)

20

1000

1400

25

1000

1400

32

1000

1400

40

1000

1400

50

1000

1400

65

1000

1400

80

1200

1500

100

1200

1500

125

1300

1500

150

1300

1500

200

1300

1600

250

1300

1600

300

1300

1600

350

1300

1600

400

1300

1800

500

1400

1800

600

1400

1800

700

1500

1900

Parts and Functions:

Parts-and-Functions
